Asset-Eyes approaches industrial racking and storage systems as engineered structures, providing complete design and documentation for warehouse pallet racking, pharmaceutical storage systems, supermarket shelving, and modular industrial assemblies. Using SolidWorks and AutoCAD, we create precise 3D models and fabrication drawings that address load distribution, beam deflection limits, seismic and impact forces, and connection integrity in line with RMI MH16.1, ASCE 7, and OSHA standards. Our designs ensure proper clearances for material handling equipment while meeting environment-specific needs such as stainless steel for pharmaceutical use or specialized coatings for food and retail. Deliverables include detailed Bills of Materials, connection drawings, and clear assembly instructions, enabling consistent, safe fabrication and installation across large or multi-site deployments without costly field modifications or compliance issues.
